> >>>Injector Dynamics ID850 Qty 4 - 850.60.14 VW Audi BMW Toyota Nissan Ford
Injector Dynamics ID850 Qty 4 - 850.60.14 VW Audi BMW Toyota Nissan Ford View larger

Injector Dynamics ID850 Qty 4 - 850.60.14 VW Audi BMW Toyota Nissan Ford

New product

Injector Dynamics ID850 Qty 4 - 850.60.14 VW Audi BMW Toyota Nissan Ford

See chart for car fitment

More details

£ 360.69 tax incl.

More info

The ID850 was added to the Injector Dynamics lineup to fill the need for a high flow injector in a small package. Specifically, GM’s LS motors, and various motorcycle applications such as Suzuki’s GSX, and Kawasaki’s ZX machines. With linearity matching that of the ID1000, and broad fitment options due to its small size, the ID850 is a highly versatile injector.
Most notable is the fact that the ID850 is the only direct fit high flow injector available for GM LS3, LS7, L76, L92, and L99 motors that is supplied with accurate characterization tables for GM PCM tuning. That means easy and accurate tuning, for a better calibration with less time invested.



  • The first injector offered with full dynamic characterization providing tuners with the data they needed to do their job properly.
  • The first injector to be offered in dead time matched sets.
  • The first high impedance high flow injector available providing stock idle and drivability on engines as small as 325cc per cylinder.
  • The first injector offered with the now standard "Top Hat Adapter" making it plug and play in nearly any application.
Basic Specifications

Nominal Flow Rate – 885cc/min @ 3.0 Bar (43.5 psi) Using Gasoline at 52 Degrees C (125 Degrees F)
Maximum Differential Fuel Pressure – 7.0 Bar (101.5 psi)
Fuel Compatibility – Compatible With All Known Fuels
Electrical Connector – USCAR

Fitment by Make & Model

Universal850.34.14
850.48.11
850.60.11
850.48.14
850.60.14
AudiAudi 1.8L Turbo850.60.14.14.4
Audi 2.0L Turbo850.60.14.14.4
Audi VR6 (12 valve)850.60.14.14.6
BMWE30 M3 88-91850.60.14.14.4
E36 M3 96-99850.60.14.14.6
E46 M3 01-06850.48.14.14.6
E90 / E92 / E93 M3 07+850.48.14.14.8
M Coupe / M Roadster 98-00850.60.14.14.6
540i / 740i850.60.14.14.8
328 96-98850.60.14.14.6
BuickTurbo Regal850.60.14.14.6
BuickGrand National850.60.14.14.6
CadillacCTS-V 09+ (LSA)850.34.14.15.8
Can AmOutlander ATV 08850.48.14.14.2
ChevroletLS3/LS7/L76/L92/L99850.34.14.15.8
LS2850.48.14.15.8
LS1/LS6850.60.14.14.8
Camaro 93-96 (LT1)850.60.14.14.8
Camaro 98-01 (LS1)850.60.14.14.8
Camaro 10+ (LS3)850.34.14.15.8
Camaro ZL1 (LSA)850.34.14.15.8
C5 Corvette (incl Z06)850.60.14.14.8
C6 Corvette850.34.14.15.8
C6 Z06 (LS7)850.34.14.15.8
C6 ZR1 (LS9)850.34.14.15.8
Cobalt SS (super)850.60.14.14.4
Dodge / ChryslerNeon SRT-4850.48.14.14.4
Caliber SRT-4850.48.14.14.4
300C SRT-8850.48.14.14.8
Challenger SRT-8850.48.14.14.8
Magnum SRT-8850.48.14.14.8
Viper 96-06850.60.14.14.10
Ram SRT-10 04-06850.60.14.14.10
FordFocus ZX3850.60.14.14.4
Focus SVT850.60.14.14.4
Focus RS850.60.14.14.4
Focus RS MK II-IV850.60.14.14.5
SVT Lightning850.60.14.14.8
F150 Harley Davidson850.60.14.14.8
Mustang SVO850.60.14.14.4
Mustang GT 88-96850.60.14.14.8
Mustang GT 97-04850.60.14.14.8
Mustang GT 05-10850.60.14.14.8
Mustang GT 2011+850.60.14.14B.8
Mustang Cobra 99-04850.60.14.14.8
Mustang GT500850.48.14.14.8
Falcon XR6850.60.14.14.6
SVT Raptor 2011+850.60.14.14.8
HoldenCommodore VT (V6)850.60.14.14.6
Commodore VTII (LS1)850.60.14.14.8
Commodore VX (LS1)850.60.14.14.8
Commodore VXII (V6)850.60.14.14.6
Commodore VY (LS1)850.60.14.14.8
Commodore VS/VY (SCV6)850.60.14.14.6
Commodore VZ (LS2)850.48.14.15.8
Commodore W427850.34.14.15.8
Commodore E-HSV850.34.14.15.8
Monaro (LS1)850.60.14.14.8
Monaro (LS2)850.48.14.15.8
Honda/AcuraAccord 92-95850.60.11.14.4
Accord 96-02850.60.11.14.4
Accord 03-07850.48.11.F20.6
Civic 88-95850.60.11.14.4
Civic 96-00850.60.11.14.4
Civic 02-05 Si850.48.14.14.4
Civic 06-11850.48.14.14.4
Odyssey 02-04850.48.11.F20.6
Prelude 92-96850.60.11.14.4
Prelude 97-01850.60.11.14.4
S2000 00-05850.48.11.F20.4
S2000 06-09850.48.14.14.4
CL 01-03850.48.11.F20.6
Integra 90-95850.60.11.14.4
Integra 96-01850.60.11.14.4
NSX 91-95850.60.11.14-O.6
NSX 96-05850.60.11.14-O.6
RSX 02-09850.48.14.14.4
TL 01-03850.48.11.F20.6
TSX 04-10850.48.14.14.4
HyundaiGenesis 2.0t 09-12850.48.14.R35.4
Genesis 2.0t 13-14850.60.14.14.4
InfinitiG35850.48.14.14.6
G37850.48.14.R35.6
G20 91-96 (11mm)850.60.11.14.4
G20 91-96 (14mm)850.60.14.14.4
G20 99-02 (11mm)850.60.11.14.4
G20 99-02 (14mm)850.60.14.14.4
LamborghiniGallardo 04+850.48.14.14.10
LexusGS300850.60.11.D.6
IS300850.60.11.D.6
SC300850.60.11.D.6
SC400850.60.11.D.8
MazdaMiata 90-05850.11.02.60.11.4
Mazdaspeed Miata850.11.02.60.11.4
Miata 06-14850.60.14.14.4
RX-7 79-84850.11.03.60.11.2
RX-7 85-86850.11.03.60.11.2
RX-7 87-92850.11.03.60.11.2
RX-7 93-95 (11mm)850.11.03.60.11.2
RX-7 93-95 (14mm)850.11.03.60.14.2
RX-8 03-11850.60.11.D.2
MitsubishiEvo III – IX850.60.11.D.4
Evo X850.48.14.14.4
Eclipse GST/GSX850.60.11.D.4
Galant VR4850.60.11.D.4
3000GT VR4850.60.11.D.6
Nissan300ZX TT (90-96) 11mm850.60.11.14.6
300ZX TT (90-96) 14mm850.60.14.14.6
350Z850.48.14.14.6
370Z850.48.14.R35.6
GTR-R32, R33, R34 (11mm)850.60.11.D.6
GTR-R32, R33, R34 (14mm)850.60.14.D.6
GTR (R35)850.48.14.R35.6
GTR (R35) FOR T1 Rails850.60.14.14-O.6
240SX-S13/S14/S15 (11mm)850.60.11.14.4
240SX-S13/S14/S15 (14mm)850.60.14.14.4
SR20DET FWD (11mm)850.60.11.14.4
SR20DET FWD (14mm)850.60.14.14.4
Patrol850.48.14.14.6
Sentra SE-R Spec V 00-06850.48.14.14.4
Titan 04+850.48.14.14.8
PontiacFirebird (93-97) LT1850.60.14.14.8
Firebird (98-02) LS1850.60.14.14.8
Trans-Am (93-97) LT1850.60.14.14.8
Trans-Am (98-02) LS1850.60.14.14.8
Turbo T/A (89 Anniv.)850.60.14.14.6
GTO (2004) LS1850.60.14.14.8
GTO (2005-2006) LS2850.48.14.15.8
G8 GT850.34.14.15.8
G8 GXP850.34.14.15.8
Porsche996/997 TT850.48.14.14.6
993/911 84-98 (non turbo)850.60.14.14.6
SaturnIon Redline850.60.14.14.4
Sky (Non turbo)850.60.14.14.4
SciontC (05-10) 2.4L850.17.01.60.11.4
FR-S (2013+)850.18.04.36.11.4
Ski-Doo1200 E-Tec 09-12850.48.14.14.3
SubaruSTi (04-06)850.18.01.48.14.4
WRX (02-11) / STi (07-11)850.48.11.WRX.4
Legacy GT / Forester XT (07-11)850.48.11.WRX.4
BRZ (2013+)850.18.04.36.11.4
ToyotaCorolla GTS (83-87) 4AGE850.60.11.D.4
MR-2 Turbo (90-96) 3S-GTE (11mm)850.60.11.14.4
MR-2 Turbo (90-96) 3S-GTE (14mm)850.60.14.14.4
MR-2 N/A (90-96) 5SFE850.60.11.D.4
MR-2 Spyder (00-05) 1ZZ-FE850.60.11.D.4
Supra Turbo (87.5-92) 7M-GTE850.60.11.D.6
Supra Turbo (93-98) 2JZ-GTE (11mm)850.60.11.14.6
Supra Turbo (93-98) 2JZ-GTE (14mm)850.60.14.14.6
Supra NA (93-98) 2JZ-GE850.60.11.D.6
Celica All-Trac (89-99) 3S-GTE (11mm)850.60.11.14.4
Celica All-Trac (89-99) 3S-GTE (14mm)850.60.14.14.4
Celica GT (00-05) 1ZZ-FE850.60.11.D.4
Landcruiser850.60.11.D.6
FJ Cruiser / 4Runner / Tundra850.60.14.D.6
VolkswagenVW 1.8T850.60.14.14.4
VW 2.0T850.60.14.14.4
VW VR6 (12v)850.60.14.14.6
YamahaFX-SHO/FZ Watercraft850.27.01.48.11.4
